Normal working condition and mounting conditions
Ambient temperature: -5°C~+40°C
2. Altitude: ≤2000m;
3.When the ambient air temperature is +40°C, the relative humidity of the air shall not be higher than 50%; a higher relative humidity is allowed at a lower temperature; for example, for the wettest month, the maximum relative humidity averaged shall be 90% while the lowest temperature averaged in that month +20°C, and special measures shall be taken for the condensation occasionally produced due to temperature change.
4.Pollution degree: 3
5.The ambient air is not significantly polluted by dust, smoke, corrosive and/or flammable gases, vapours or salt.0A 1600
Main tachnical data
1.Rated working voltage AC 380V,DC220V
2.Main technical performance and parameters.
conventional thermal current | 100 | 200 | 400 | 600 | 1000 | |
Rated operating current | 100 | 200 | 400 | 600 | 1000 | |
Breaking capacity | AC 380V.COSφ=0.72-0.8 | 100 | 200 | 400 | 600 | 1000 |
DC T=0.01-0.011S 220V | 100 | 200 | 400 | 600 | 1000 | |
Mechanical life (times) | 10000 | 10000 | 10000 | 5000 | 3000 | |
Electrical life (times) | 1000 | 1000 | 1000 | 500 | 300 | |
1S short time withstand current | 6 | 10 | 20 | 25 | 30 | |
Peak withstand current | 15 | 20 | 30 | 40 | 50 | |
Operating force | ≤300 | ≤300 | ≤400 | ≤400 | ≤450 | |
